PTR Terminal Block AKZ350 2pol pitch 5.08 50350020001FV
€0.63
Available, delivery time: 2-5 days
Product information "PTR Terminal Block AKZ350 2pol pitch 5.08 50350020001FV"
PTR Hartmann AKZ350 – 2-pole, 5.08 mm pitch, screw terminal block. Type 50350020001F. PCB-mount. Compact, directly solderable screw terminal for simple 2-wire connections on boards. Compact and reliable.
Key Technical Specifications
- Manufacturer: PTR Hartmann
- Series: AKZ350
- Poles: 2
- Pitch: 5.08 mm
- Type: Screw terminal block, PCB-mount
Frequently Asked Questions
Both are directly solderable screw terminal blocks at 5.08 mm pitch. AKZ350 is the more compact and affordable base variant for simple connections. AKZ250 is slightly larger and more robust. For simple 2-wire connections in LED projects, AKZ350 is a good choice.
For supply voltage (+ and −) to a PSU board, single-colour LED loads, or power output terminals on custom LED controller boards.
| Cable cross-section: | 1.5 mm² |
|---|---|
| Connection: | Schraubanschluss |
| Connection Type: | Anschlussklemme |
| Current: | 15A |
| Fastening: | Leiterplattenmontage |
| Height: | 13.5 mm |
| Length: | 9 mm |
| Number of pins: | 2 |
| Pitch: | 5.08 mm |
| Width: | 10.16 mm |
