Why does the green LED deliver significantly more lumens than the blue or red?

The human eye is most sensitive in the green range (~555nm). Green LEDs at 525nm are close to this maximum and therefore achieve the highest lumen values for the same radiant power. This is why green LEDs in RGB systems often need to be dimmed to achieve a balanced colour mix.

What is this LED used for?

As the green channel in RGB or RGBCCT systems, for green accent lighting, colour effects on film sets, or as an individual channel in custom-populated GKORE modules.

Is this LED available in other wavelengths?

Available in the shop: blue 465nm (A30018), red 625nm (A30020), as well as cyan and further wavelengths.

LED SMD 2835 Green 525nm 3V 0.5W 150mA 45lm

Name: LED SMD 2835 Green 525nm 3V 0.5W 150mA 45lm
Brand: Graf Lichttechnik
SKU: A30019
Price: 0.54 EUR
Availability: InStock

Green mid-power SMD LED with 45 lm output. Perfect for decorative and functional lighting.

€0.54

Available, delivery time: 2-5 days

Product number: A30019

Stock: 8000

Manufacturer: Graf Lichttechnik

Product information "LED SMD 2835 Green 525nm 3V 0.5W 150mA 45lm"

LED SMD 2835 – green 525 nm, 3 V, 0.5 W, 150 mA, 45 lm. Monochromatic green mid-power LED for RGB systems, accent lighting and decorative light effects. GKORE CINE Series.

Key Technical Specifications

Package: 2835 SMD
Light colour: green, 525 nm
Power: 0.5 W at 150 mA / 3 V
Luminous flux: 45 lm
Beam angle: 120°

Beam Angle:	120°
Brightness:	45 lm
Color:	grün
Forward Current:	150 mA
Forward Voltage:	3 V
LED Type:	2835
Power:	0,5 W
Wavelength:	525 nm
